Thanks to their modular design, the belt conveyors can be adapted to the system environment and requirements at any time, ensuring optimum system utilization. The main component of every belt conveyor is the drive unit (as a head or middle station) with the standard shaft-mounted geared motor and integrated tensioning device. Depending on the drive version, one or two return stations are added, as well as the belt carriers (conveyor shaft), which are variable in length. Height and angle-adjustable welded steel supports or ceiling suspensions are used as support structures. The belt to be used depends on the application of the belt conveyor. PROFLUSS only uses high-quality, flame-retardant material for this purpose.

They are available as 1, 2 or 3 belt combinations in the form of single or double check-in units. The usable width of a check-in line depends on the international requirements and the sometimes differing national standards for baggage to be transported. With their modern appearance, the virtually silent tele-check-in conveyors from PROFLUSS can be integrated into any airport terminal design concept and, thanks to their ergonomics and telescoping capability, provide the operator with all the necessary advantages of a modern baggage handling system. PROFLUSS uses only high-quality, flame-retardant material for the belts, specially designed for check-in applications.

The body is made entirely of steel, the visible outer walls are made of stainless steel or painted sheet steel, depending on the customer's requirements. Alternative materials can also be used, in particular the work and storage surfaces can be supplied in wood, melamine, natural stone or similar. Alternative shapes and designs can be coordinated and implemented according to customer requirements.

The PROFLAT carousel is supplied in modular design and almost any shape can be realized according to the customer's wishes. Each module consists of a frame made of sturdy steel and aluminum profiles. The drive unit can be variably planned into each standard module, which means that a total round conveyor length (in relation to the endless transport chain) of up to 70 m can be realized. Longer lengths can be equipped with additional drive units. The maintenance-free conveyor chain made of wear-free aluminum is equipped with quiet-running 2-component chain rollers (PU bandage / PA core), which are also maintenance-free. The identical rollers are used for the transport scales carriers, which minimizes spare parts inventory. The shed carriers themselves are made of sheet steel using state-of-the-art technology. PROFLUSS uses only high-quality PU material in flame-retardant B2 quality for the transport sheds, specially designed for airport applications. The cladding is made of stainless steel as standard, but can also be painted sheet steel on request.

The PROMOVE swivel rejector is equipped with a low-maintenance swivel arm made of aluminum profiles, which is supported by a sturdy steel structure. The height of the frame is adapted to the corresponding conveyor technology at the factory in accordance with the intended use. The swivel arm is aligned at an appropriate distance above the conveyor belt of the conveyor system in question. The conveyor belt, for which PROFLUSS only uses high-quality, flame-retardant material, is guided on the running side by means of a V-ledge to prevent the belt from running.

PROFLUSS PROBELT belt conveyors can be integrated into practically any material flow. Mainly used at airports, they are also used in sorting and logistics systems. Whether in horizontal, ascending or descending versions, there are virtually no limits to the designs available

The PROSLOPE carousel is supplied in modular design and almost any desired shape can be realized according to the customer's wishes. Each module consists of a frame made of sturdy steel and aluminum profiles. The drive unit can be variably planned into each standard module, which means that a total round trip length (in relation to the endless transport chain) of up to 70 m can be realized. Longer lengths can be equipped with additional drive units. The maintenance-free conveyor chain made of wear-free aluminum is equipped with quiet-running 2-component chain rollers (PU bandage / PA core), which are also maintenance-free. The same rollers are used for the transport scaling carriers, which minimizes spare parts inventory. The scaling carriers themselves are made of sheet steel using state-of-the-art technology. PROFLUSS uses only high-quality PU material in flame-retardant B2 quality for the transport and edge sheds, specially designed for airport applications. The cladding is made of stainless steel as standard, but can also be painted sheet steel on request.
